| 夹套直管 | ||||||||||||
| Jacket Straight Pipe | ||||||||||||
| 不含活套法兰的重量 | ||||||||||||
| DaN: Weight without loose flange (kg) | ||||||||||||
| L | DN | |||||||||||
| 25 | 32 | 40 | 50 | 65 | 80 | 100 | 125 | 150 | 200 | 250 | 300 | |
| 150 | 1.6 | 2.5 | 2.7 | 3.6 | 5.2 | 7 | 8.6 | 12.4 | 14.6 | - | - | - |
| 200 | 2.0 | 2.7 | 2.9 | 4.1 | 5.9 | 8.1 | 10.3 | 14.2 | 17.1 | 26.1 | 36.7 | 45.7 |
| 250 | 2.2 | 3.1 | 3.2 | 4.7 | 6.7 | 9.2 | 11.7 | 16 | 19.6 | 29.9 | 42.7 | 52.7 |
| 300 | 2.3 | 3.8 | 4 | 5.2 | 7.4 | 10.3 | 13.3 | 18 | 22.1 | 33.7 | 48.6 | 59.8 |
| 400 | 2.7 | 4.3 | 4.7 | 6.1 | 8.8 | 12.2 | 16.4 | 21.8 | 27.2 | 41 | 60.3 | 73.4 |
| 500 | 3.4 | 5.4 | 5.6 | 7.8 | 11.4 | 15.8 | 21.4 | 28.2 | 36 | 54 | 80 | 97.2 |
| 600 | 3.8 | 6.2 | 6.4 | 9 | 13 | 18.2 | 24.8 | 32.4 | 41.6 | 62.4 | 92.8 | 112.8 |
| 700 | 4.4 | 6.8 | 7.2 | 10.2 | 14.6 | 20.6 | 28.2 | 36.6 | 47.2 | 70.6 | 105.8 | 129.8 |
| 750 | 4.8 | 7.2 | 7.6 | 10.6 | 15.4 | 21.6 | 29.8 | 38.6 | 50 | 74.8 | 112.4 | 135.8 |
| 800 | 5.0 | 7.6 | 8 | 11.2 | 16.2 | 22.8 | 31.6 | 40.6 | 52.8 | 79 | 118.8 | 143.6 |
| 1000 | 6.0 | 8.8 | 9.3 | 13.4 | 19.2 | 27.4 | 38.2 | 49 | 64.2 | 95.6 | 144.8 | 174.6 |
| 1500 | 9.2 | 13.4 | 15 | 20.9 | 29.9 | 42.7 | 60.5 | 76.6 | 101.6 | 150.9 | 230.6 | 277.4 |
| 1800 | 10.8 | 15.8 | 17.4 | 24.6 | 35.4 | 50.4 | 71.5 | 90.4 | 120.1 | 178.4 | 273.5 | 328.2 |
| 2000 | 11.9 | 17.4 | 19.4 | 27.1 | 38.7 | 55.4 | 79 | 99.4 | 132.4 | 196.9 | 302.1 | 362.3 |
| 2500 | - | - | - | 33.2 | 47.5 | 68.2 | 97.5 | 122.1 | 163.7 | 242.4 | 373.3 | 447.5 |
| 3000 | - | - | - | 39.2 | 56.3 | 80.7 | 115.9 | 145 | 194.7 | 288.4 | 444.8 | 532.6 |
搪玻璃夹套直管
